Welded Copper Nickel Pipes ASTM B467 C70600 Electric Resistance 6m Alloy Tubing

    Buy cheap Welded Copper Nickel Pipes ASTM B467 C70600 Electric Resistance 6m Alloy Tubing from wholesalers

    Buy cheap Welded Copper Nickel Pipes ASTM B467 C70600 Electric Resistance 6m Alloy Tubing from wholesalers
    • Buy cheap Welded Copper Nickel Pipes ASTM B467 C70600 Electric Resistance 6m Alloy Tubing from wholesalers

    Welded Copper Nickel Pipes ASTM B467 C70600 Electric Resistance 6m Alloy Tubing

    Ask Lasest Price
    Brand Name : Kasugai
    Model Number : ASTM B467 C70600 EWR
    Certification : ISO PED AD2000
    Price : Negotiable
    Payment Terms : L/C, T/T
    Supply Ability : 300 ton per month
    Delivery Time : 30 - 60 working days
    • Product Details
    • Company Profile

    Welded Copper Nickel Pipes ASTM B467 C70600 Electric Resistance 6m Alloy Tubing

    ASTM B467 C70600 EWR Electronic Resistance Weld Copper Nickle Pipe


    Product Information

    Product NameASTM B467 C70600 EWR Electronic Resistance Weld Copper Nickle Pipe
    Size Range1/4” to 10” (Sch40), 1/4” to 4” (Sch80)
    Length6 meters or as customer required
    StandardsASTM B467
    Grade90/10 Copper Nickle
    End ProcessPlain End, Beveled End

    ASTM B467 specification standards are for welded copper nickel pipes of varying compositions.

    ASTM B467 Pipe Chemical Composition (%)

    GradeUNSMn, maxCu, minPb, maxFe, maxNi, maxZn, max
    90/10C706001.088.60.051.89-111

    ASTM B467 Tubing Mechanical Properties

    GradeUNSHardness Range, HBYield 0.2%, min (MPa)Tensile, min (MPa)Elongation, min (%)
    90/10C7060070-12010528027

    Average Diameter Tolerance

    Specified DiameterTolerance Applies toTolernaces, plus and minus,B in.for. Ybes of Copper Alloy UNS Nos. C70600, C71000, and C71500
    Up to 1/8, inclinside diameter0.003
    Up to 1/8, incloutside diameter0.0025
    Over 1/8 to 5/8, inclinside or outside0.0025
    Over 5/8 to 1,inclinside or outside0.003
    Over 1 to 2,inclinside or outside0.004
    Over 2 to 3,inclinside or outside0.005
    Over 3 to 4,inclinside or outside0.006
    Over 4 to 5,inclinside or outside0.008
    Over 5 to 6 ,inclinside or outside0.009
    Over 6 to 8,inclinside or outside0.010
    Over 8 to 10,inclinside or outside0.013

    Copper Nickle Pipe Standards

    TitleDescription
    ASTM B469Seamless Copper Alloy Tubes for Pressure Applications
    ASTM B466Seamless Copper Nickel Pipe and Tube
    ASTM B552Seamless & Welded Copper Nickel Tubes for Water Desalting
    ASTM B543Welded Copper & Copper Alloy Heat Exchanger Tube
    ASTM B608Welded Copper Alloy Pipe
    ASTM B467Welded Copper Nickel Pipe
    ASTM B111Copper & Copper Alloy Seamless Condenser Tubes & Ferrule Stock
    ASTM B359Copper & Copper Alloy Seamless Condenser & Heat Exchanger Tubes with Integral Fins
