    ISO 49-1994(E) CL150 AISI 304 Stainless Steel Casting Bushing

    ISO 49-1994(E) CL150 AISI 304 Stainless Steel Casting Bushing


    Product Information

    A stainless steel cast threaded bushing is a type of fitting used in piping systems to reduce the size of a threaded connection. It is typically used to connect pipes or fittings with different thread sizes, providing a secure and leak-free joint. Stainless steel cast threaded bushings are commonly used in various industries where corrosion resistance, durability, and strength are essential, such as in chemical processing, oil and gas, and marine applications.


    Threaded Connection: The cast threaded bushing has internal and external threads that allow it to be screwed into a pipe or fitting with a larger thread size, while the other end can accommodate a smaller threaded connection.

    Stainless steel cast threaded bushings are available in various sizes to accommodate different pipe diameters and thread specifications.


    Corrosion Resistance: Stainless steel cast threaded bushings are ideal for applications where resistance to corrosion and harsh environments is necessary, making them suitable for use in challenging industrial settings.

    Product NameISO 49-1994(E) CL150 AISI 304 Stainless Steel Casting Bushing
    Thread TypesASME B1.20.1(NPT)
    DimensionsISO 49-1994(E)
    Size Range1/4” to 4"
    Pressure ClassClass 150
    MaterialsAISI 304/L

    Standard & Materials:AISI 304L

    The SAE/ANSI 304 (AISI 304) is the most commonly available and used type of stainless steel. It is also referred to as 18/8 stainless steel, A2 stainless steel (as per the ISO 3506), or 304S15 (as per the British Standard). This is an austenitic chromium-nickel alloy which practically means that it has a very high corrosion resistance. It is also nonmagnetic and can’t be hardened through heat treatment. As AISI 304 can withstand extremely corrosive environments and can be shaped, machined and welded relatively easy, it is very popular for a wide range of applications.


    AISI 304/L Chemical Composition (%)

    GradeC, maxCrMn, maxNiP, maxS, maxSi, max
    AISI 3040.0818~2028~10.50.0450.031
    AISI 304L0.0318~2028~120.0450.031

    AISI 304/L Mechanical Properties

    Mechanical Properties304304L
    Hardness, Knoop138158
    Hardness, Rockwell B7082
    Hardness, Vickers129159
    Tensile Strength, Ultimate505 MPa564 MPa
    Tensile Strength, Yield215 MPa210 MPa
    Elongation at Break70%58%
    Modulus of Elasticity193~200 GPa193~200 GPa
    Charpy Impact325 J216J

    ISO 49-1994 Dimensions of Bushing (mm)


    Fitting Sizes

    (inches)

    Patterns

    Dimensions

    (mm)


    Laying Lengths (mm)
    abz
    ¼ ×⅛I2013
    ⅜ ×⅛II2013
    ⅜ ×¼I2010
    ½ ×⅛II2417
    ½ ×¼II2414
    ½ ×⅜I2414
    ¾×¼II2616
    ¾ ×⅜II2616
    ¾ ×½I2613
    1 ×¼II2919
    1 ×⅜II2919
    1 ×½II2916
    1 ×¾I2914
    1¼ ×⅜II3121
    1¼ ×½II3118
    1¼ ×¾II3116
    1¼ ×1I3114
    (1½ ×⅜)II3121
    1½ ×½II3118
    1½ ×¾II3116
    1½ ×1II3114
    1½ ×1¼I3112
    2 ×½III354835
    2 ×¾III354833
    2 ×1II3518
    2 ×1¼II3516
    2 ×1½II3516
    2½ ×1III405437
    2½ ×1¼III405435
    2½ ×1½II4021
    2½ ×2II4016
    3 ×1III445942
    3 ×1¼III445940
    3 ×1½III445940
    3 ×2II4420
    3 ×2½II4417
    4 ×2III516945
    4 ×2½III516942
    4 ×3II5121


    Benefits of Stainless Steel Casting Screw Fittings


    1. Stainless steel casting combines good corrosion resistance and high strength, which allows the reduction in wall thickness and weight of pipe fittings. Besides, it can withstand very high flow rates, making it capable to withstand long-term exposure to the elements in almost any environment.
    2. Cast stainless steel pipe fittings can be used in all types of water, including drinking water in public supply. They have an excellent resistance to the full range of potable waters, including various chloride levels. At the end of its useful life, cast stainless steel is fully recyclable and retains a higher residual scrap value than ordinary cast steel.
    3. Stainless steel casting of pipe fittings requires low maintenance and does not need an additional coating, in both indoor and outdoor applications. The expected lifetime of a stainless steel pipe fitting is more than 50 years, reducing system down time, replacement and maintenance costs over the life of the installation.
    4. Last but not the least, stainless steel casting is afforable to produce any type of pipe fittings, and it can produce pipe fittings in both high and small volumes.
